Dust Control Spray Equipment & Systems

The ZHP Truck-Mounted Transfer System is available with multiple power configurations. For trucks under 10,000 gallons, Zircon offers compressed air-operated diaphragm pump systems when air is available and 12 VDC motor-driven diaphragm pumps when air is not available. For larger water trucks over 10,000 gallons, 120 VAC or 480 VAC custom-made pump systems can be placed at the fill site. Contact Zircon Industries to confirm the correct configuration for your truck capacity, available power source, and fill-site setup.

ZHP Water Wetter is commonly introduced at 1 gallon of ZHP per 2,000 gallons of water. The ZHP Truck-Mounted Transfer System helps simplify this process by directly injecting product into the water truck at approximately 2 gallons per minute. This reduces the need for labor-intensive manual introduction and helps operators maintain a more consistent water-to-product ratio during routine dust-control watering programs.

Yes. The ZHP Truck-Mounted Transfer System can be configured for different truck sizes and fill-site setups. For trucks under 10,000 gallons, the system can use an air-operated diaphragm pump or 12 VDC motor-driven diaphragm pump with a custom mounting bracket, intake hose, quick connect, and custom suction bar. For trucks over 10,000 gallons, Zircon offers 120 VAC or 480 VAC pump systems that are placed at the fill site. Contact Zircon Industries to review your truck capacity, available power source, mounting requirements, and plumbing needs.

ZHP Water Wetter and compatible spray or transfer systems support dust-control watering programs across aggregate, mining, utility, steel, trucking, lumber yard, construction, road-maintenance, and industrial site applications. These systems are useful for operations that manage dust on haul roads, unpaved roads, gravel surfaces, aggregate yards, industrial roads, and other surfaces where water-based dust suppression is part of the maintenance program.

The BZM-120AC Manual Sprayer is a portable 120 VAC, 2.0 A sprayer for manual liquid application tasks. It supports up to four 1/4K5 nozzles at a maximum elevation of 100 ft and uses an on-demand pump regulated by a 40 PSI pressure sensor. The unit includes a fiberglass enclosure with carrying handle, a 12 ft suction hose with foot valve and strainer, and a 1/2-inch hose barb for sprayer output. Total weight is approximately 20 lbs. The adjustable timer can be set from 0.1 second to 180 hours.

For the BZM-120AC Manual Sprayer, run clean water through the unit for 5 minutes before end-of-season storage. This helps flush remaining product from the pump and lines before the sprayer is stored. For the ZHP Truck-Mounted Transfer System, contact Zircon Industries at **800-547-4328** for maintenance, flushing, storage, and startup guidance based on your truck setup, pump configuration, product use, and site conditions.
